ตลับหนีบสายไฟแบบต่อตรง
สั่งพิมพ์หน้านี้ |
ส่งแบบสอบถาม |
ใส่ลงในตะกร้า |
·Poly carbonate,UL 94V-0 flame-retardant shell.
·Spring force connector constructed from tinned copper plate,spring steel and steel frame.
·Rated to 600V max. for building wiring and 1000V max. lighting fixtures and signs.
·Color-coded for quick and easy identification.
·For use with rigid/ solid and flexible / stranded conductors.
*new
·Spring force connector constructed from tinned copper plate,spring steel and steel frame.
·Rated to 600V max. for building wiring and 1000V max. lighting fixtures and signs.
·Color-coded for quick and easy identification.
·For use with rigid/ solid and flexible / stranded conductors.
*new
ITEM.NO. | COLOR | POLES | ELECTRICAL RATINGS | CLAMPING AREA WIRE RANGE |
PC352J | White | 2 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC353J | Orange | 3 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC354J | Red | 4 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC355J | Yellow | 5 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC356J | Blue | 6 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC358J | Grey | 8 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
PC3510J | Green | 10 |
24A,450V,T110 600V,105℃(221℉) |
0.5-2.5mm2, Rigid 22-12 AWG,Sol/Str Cu |
